[ES-104] 6-IN-1 Integrated Compact Sensor

SKUES-104Categories Advanced, LoRaWAN® IAQ Sensors, M SeriesMeasures CO2, Humidity, PM 10, PM 2.5, Temperature, TVOC

The Atomsenses ES-104 is a LoRaWAN electrochemical-type gas detecting sensor with a high sensitivity to low concentrations of detected gas, high selectivity, and a stable baseline.

Typically use cases includes Airport, Hospital etc.

The sensor has an Ultra-low Power design and smart firmware, allowing it to last up to 5 years with three AA-type batteries. It can transmit data over long distances to any brand of LoRaWAN gateway.

Main features of the sensor

Wireless communication using the LoRaWAN protocol
Real-time air quality monitoring
Function of measuring various gases including temperature, humidity and CO2 concentration in the room, office , building etc.
Simple device configuration
Advanced ultrasonic sensor to deliver high accuracy and stable measurement
It has a housing with an IP30 protection level
Designed for wall mounting
Energy saving – batteries last up to 5 years of use

Main features of the sensor

Comprehensive IAQ sensor for detecting Temperature, Humidity, CO2, PM1.0, PM2.5, PM10, TVOC, NO2, HCHO, NH3, H2S etc. accurately and economically.

Up to 5 years powerful batter

Ultra-low power sensing technology with Ultra-low power wireless technology allowing the sensor to last up to 5 years with two (small) / four (large) ER14505 batteries with a capacity of 2700 mAh

Industrial Grade High Accuracy

Advanced ultrasonic sensor to deliver high accuracy and stable measurement

Supports ODM & OEM

LoRaWAN communication protocol

LoRaWAN is a global communication standard for IoT networks, based on LoRa technology, which is characterized by a long range.

Thanks to this protocol, devices can communicate with network gateways over a distance of several kilometers in urban environments and up to several dozen kilometers in rural areas. At the same time, LoRaWAN-based devices are known for their low power consumption, making them an ideal choice for applications where batteries need to function for years without the need for recharging. In response to different network conditions, LoRaWAN can adjust the transmission rate, which helps optimize coverage and energy consumption.

Description

Improving Energy Efficiency and Indoor Comfort

Integrated 6 types of sensor to measure various ambience conditions

Comprehensive IAQ sensor for detecting Temperature, Humidity, CO2, PM2.5, PM10, TVOC accurately and economically.

LoRaWAN communication

LoRaWAN communication standard to allow sensor connect to any LoRaWAN Gateway on the market

Up to 5 years powerful batter

Ultra-low power sensing technology with Ultra-low power wireless technology allowing the sensor to last up to 5 years with 03 x AA batteries

Industrial Grade High Accuracy

Advanced ultrasonic sensor to deliver high accuracy and stable measurement

Supports ODM & OEM

Additional information

Weight	0.5 kg
Dimensions	125 × 125 × 28.5 cm
